| Technical specifications | |
|---|---|
| Input Voltage | 12/24 Volt DC |
| Output voltage | 12/24 Volt DC |
| Wattage | max. 60 Watt at 12 Volt DC max. 120 Watt at 12 Volt DC |
| Type | 100 mm mains lead with LED plug-in connection 100 mm lead with LED socket |
| Dimensions | sensor 53 x 45 x 7.5 mm mounting bracket 62 x 72 x 4 mm |
| Installation | mounting bracket with double adhesive tape |
| Remarks | installation for example hinter panels or mirrors, controlled by knocking on the surface, in the area of the sensor, knock once = On/Off knock twice = CCT colour changing (3-pin system) |
| Article code |
|---|
| 39.536.001 |
